HARDWARE COMPARISON CHART
Hardware chart:
For your convenience, we have identified the hardware used in the assembly of this product. This chart is provided
to help you identify those items that may be unfamiliar to you.
NO. DESCRIPTION
QTY.
9
Console Support Fixing
Plate 2
11
M6 x 15mm Console
Fixing Screw
2
16
#8 x 25mm Screw
8
17
Handlebar Fixing Plate
2
18
M8 x 25mm Allen Head
Bolt 6
19
M8 x 15mm Allen Head
Bolt 4
A Wrench
1
B Screw
Driver
1
C Allen
Wrench
1
MILIMETERS
