Smooth Fitness 9.17HRO User Manual
Page 16
SMOOTH 9.17HRO MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
16
ASSEMBLY
STEP 5:
Remove the Bracket Screw (135) from Console Tray Fixing Plate (21). Attach the Console Tray (22) to the Console
Housing (3) and secure by screwing the Bracket Screw (135) through the Console Tray Fixing Plate (21) and into the
Console Housing (3), as shown in FIG3.
FIG3
