Instructions for the user

7.2 Hobs with touch-control buttons

When an icon is pressed the unit beeps to confirm.

To operate the panel of the hobs equipped with touch-controls, lightly press the icons printed on its
surface.

On first connection to the electrical mains, an operating check will be carried out automatically
and all the indicator lights will come on for a few seconds.

7.2.1

Switching on the hob

When not in use, all hob components will be switched off. Hold down

for 2 seconds to switch the

hob on; a led will turn on above the symbol to confirm that the hob is lit. If no functions are used within
30 seconds of switching the hob on, it will automatically turn itself off.

7.2.2

Single cooking zones

The associated cooking zone is indicated close to each control zone. For example, the symbol

identifies the knob that controls the rear right-hand cooking zone.
After turning on the hob as described in paragraph “7.2.1 Turning on the Hob”, press the keys

and

to activate the cooking zone (display indicating 0) and adjust the power at which it should operate.

The power settings range from a minimum of 1 to a maximum of 9.
You must adjust the power within 5 seconds from when the cooking zone is activated, otherwise it will
automatically deactivate.
Press the

and

buttons in the following way to activate the cooking zone and adjust its power:

press the symbol

(0 appears on the display: this means that the cooking zone is activated);

by continuing to press the symbol

, you can adjust the power of the cooking zone up to the

maximum value of 9;

if you instead press the symbol

, you adjust the power of the cooking zone down to the

minimum value of 1.

7.2.3

Dual cooking zones

To activate heating of the dual cooking zone, once power 9 is reached by following the instructions
provided in paragraph “7.2.2 Single cooking zones”, press the

again. Now the maximum power of

the cooking zone is activated, and is shown by the LED light turning on next to the number indicating
the operating power. Press on the symbols

and

to adjust the power of the dual cooking zone to

the desired value.

7.2.4

Triple cooking zones

To activate heating of the triple cooking zone, once power 9 of the dual cooking zone is reached by following
the instructions provided in paragraph “7.2.3 Dual cooking zones”, press the

again. Now the maximum

power of the triple cooking zone is activated, and the LED indicating the operating power remains fix. Press
on the symbols

and

to adjust the power of the triple cooking zone to the desired value.

7.2.5

Heating zone

This zone, which is present only on some models in the range, keeps the area inside the dashed line
at a temperature of approximately 90°C. It is used for warming dishes up or keeping them hot. If the
hob is not locked, simply press the button

to switch it on. Press the button

to switch it off.

7.2.6

Cooking zone lock-out

The cooking zone lock-out function is a user safety functions. It locks out the hob controls to prevent
the ceramic cooking zones being switched on accidentally.
Hold down

for 1 second to lock out the hob. The hob can be reactivated by holding down

again

for 1 second.

7.2.7

Cooking zone layout

REAR LEFT

REAR RIGHT

REAR
CENTRAL

CENTRAL

FRONT LEFT

FRONT RIGHT

FRONT
CENTRAL

OVAL
CENTRAL
