Troubleshooting
This section may help you isolate the cause of a problem
and as a result, eliminate the need to contact technical
support.
Specifications
Picture performance
LCD panel a-Si TFT Active Matrix
Pixel efficiency 99.99 %
Viewing angle
(up/down/left/right, contrast > 10:1)
89°/89°/89°/89° (typical)
Scan Under scan –3 %
Normal 7 %
Over scan 20 %
Efficient picture size
Approx. 376 × 301, 482 mm (w/h, dia)
(14
7
/ 8 × 11
7
/ 8 , 19 inches)
Resolution H: max. 1,280 dots
V: max. 1,024 lines
Aspect ratio 5:4
Input/output connectors
Input
Composite input connector
BNC type (1)
1 Vp-p ± 3dB sync negative
Y/C input connector
4-pin mini DIN (1)
Y: 1 Vp-p ± 3dB sync negative
C: 0.286 Vp-p ± 3dB (NTSC burst
signal level)
0.3 Vp-p ± 3dB (PAL burst signal
level)
RGB/Component connectors
BNC type (3)
RGB input: 0.7 Vp-p ± 3dB (Sync On
Green, 0.3 Vp-p sync negative)
Component input: 0.7 Vp-p ± 3dB
(75% chrominance standard color
bar signal)
External Sync input connector
BNC type (1)
0.3 to 4 Vp-p ± bipolarity ternary or
negative polarity binary
Remote input terminal
Parallel remote
Modular connector 8-pin (1)
RS-232C (serial remote)
D-sub 9-pin (1)
HD15 input connector
HD D-sub 15-pin (1)
R/G/B: 0.7 Vp-p, 75 ohms, sync
positive (when G channel is sync
negative, the internal sync can be
used. 0.3 Vp-p)
Symptom Settlement
The display is
colored in green or
purple. Select the correct input by pressing the
INPUT key.
The black bars
appear at the upper
and lower positions
of the picture. When the signal aspect ratio is different
from that of the LCD panel, the black
bars appear. This is not a failure of the
unit.
The key on the front
panel do not work. The key protection function works. The
key inhibit function can be set in the
KEY INHIBIT menu and REMOTE
menu.
Set as follows.
When “KEY INHIBIT” is set to
“ON”: Set to “OFF”.
When “SERIAL REMOTE” is set to
“RMT ON”: Set to “RMT OFF” or
“RMT & LCL”.
When “KEY INHIBIT” and
“SERIAL REMOTE” are set to
“ON”: Set “KEY INHIBIT” to “OFF”
and then “SERIAL REMOTE” to
“RMT OFF” or “RMT & LCL”.
The image is not
displayed on the
monitor. After confirming the connections and
the settings in the INPUT SELECT
menu (on page 25), select the correct
input by pressing the INPUT key.
The image is
disturbed. Select “EXT” or “INT” correctly in the
“SYNC” setting of the USER CONFIG
menu (on page 22).
The “FAN ERROR”
message is displayed. The fan for cooling the unit does not
work.
Turn off the power and contact an
authorized Sony dealer.
