Technical Data
SMA
Technologie AG
Page 78
SMC50A_60A-IEN073320
Installation Guide
14.2 Sunny Mini Central SMC 6000A
Description
Short
descr.
Setting
PV Generator Connection Data
Max. input open circuit voltage
U
PV 0
600 V (based on -10 °C cell
temperature)
Input voltage, MPP range
U
PV
213 V - 600 V @ UACmin
(246 V - 600 V DC @ 230 V AC)
Max. input current
I
PV, max
26 A
Max. input power
P
DC
6300 W
All-pole isolator on
the DC input side
DC plug connector
Overvoltage protection
thermally monitored varistors
Voltage ripple
U
PP
< 10 % of the input voltage
Personal protection
insulation monitoring
(Riso > 1 MW)
Operating consumption
< 7 W
Reverse polarity protection
via short-circuit diode
