4 Overview of the Device
4.1 Identification
You can identify the Sunny Mini Central with the aid of the name plate (see figure
below). The name plate is found on the right-hand side of the housing (when viewed
from the front). It contains information regarding the device type, serial number, device-
specific key data, the CE mark and SMA contact information.
The following is an example of a Sunny Mini Central SMC 6000A name plate:
SMA Technologie AG
www.SMA.de
SUNNY MINI CENTRAL
Photovoltaic string inverter Made in Germany
Model Serial No.
SMC 6000A 2000165882
V
DC max
V
DC MPP
I
DC max
V
AC nom
f
AC nom
P
AC nom
I
AC max
outdoor
600 V
246-600 V
26 A
230 V
50/60 Hz
6000 W
26 A
1
GÜTEZEICHEN
Solar
*2000165882*
VDE 0126-1-1 (2.06)
cos
j
Device type Serial number
Country-specific
standard for the
grid isolation point
according to which
the device may be
preset
