SMC Networks Sunny Mini Central SMC 5000A - Manual (Page 24)

Installation SMA Technologie AG
Page 24 SMC50A_60A-IEN073320 Installation Guide
8 Close the recessed grips with the
handle covers provided in the
accessories kit.
They are required to adequately
prevent insects entering the unit!
If required, new handle covers can be
ordered from SMA (contact: see
Page 92).
Optional Anti-theft Protection
9 To protect the Sunny Mini Central
against theft, the rear face can be
secured to the wall at the bottom using
2 so-called single-use bolts. The other
two holes are spare, in case you take
down the Sunny Mini Central and then
mount it again, and the screw stumps
from the first single-use bolts still
protrude from the wall.
The exact position of the holes can be seen in the illustration of the rear panel
in section 4.2 "Dimensions" (Page 13).
Step Instruction
2
1
