Architectural Series ™
A
R C H I T E C T U R A L
S
E R I E S
S
P E A K E R A N D
W
O O F E R
O
W N E R
’
S
M
A N U A L
Z8, Z8F, Z8R, Z8S
Tweeter: 1” (25mm) ber yllium dome,
ferrofluid cooled, pivoting
Midrange: 4” (102mm) ber yllium cone,
rubber surround, pivoting
Woofer: 8” (203mm) ber yllium co ne,
rubber surround, extended pole piece
(Z8, Z8F), pivoting (Z8R/Z8S)
Frequency Response: 30Hz – 20kHz ±3dB
Impedance: 6 ohms nominal; 4 ohms
minimum
Power Handling: 5 watts minimum;
175 watts maximum
Sensitivity: 91dB SPL (2.83V/1 meter)
Adjustments: Tweeter and Midrange Level
(±3dB)
X8, X8R, X8S
Tweeter: 1” (25mm) silk dome, ferrofluid
cooled, pivoting
Midrange: 4” (102mm) carbon fiber
cone, rubber surround, pivoting
Woofer: 8” (203mm) carbon fiber co ne,
rubber surround, pivoting (X8R/X8S)
Frequency Response: 32Hz – 20kHz ±3dB
Impedance: 6 ohms nominal; 4 ohms
minimum
Power Handling: 5 watts minimum;
150 watts maximum
Sensitivity: 91dB SPL (2.83V/1 meter)
Adjustments: Tweeter and Midrange Level
(±3dB)
X8W, X8WR, X8WS
Woofer: 8” (203mm) long-throw
carbon fiber co ne, rubber surround
Frequency Response: 35Hz – 250Hz
Z6, Z6R, Z6S
Tweeter: 1” (25mm) ber yllium dome,
ferrofluid cooled, pivoting
Woofer: 6½” (165mm) ber yllium co ne,
rubber surround, extended pole piece
(Z6), pivoting (Z6R/Z6S)
Frequency Response: 40Hz – 20kHz ±3dB
Impedance: 6 ohms nominal; 4 ohms
minimum
Power Handling: 5 watts minimum;
150 watts maximum
Sensitivity: 90dB SPL (2.83V/1 meter)
Adjustments: Tweeter Level (±3dB)
X6, X6R, X6S
Tweeter: 1” (25mm) silk dome, ferrofluid
cooled, pivoting
Woofer: 6½” (203mm) carbon fiber
c o n e , r u b b e r s u r r o u n d , p i v o t i n g
(X6R/X6S)
Frequency Response: 43Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms
minimum
Power Handling: 5 watts minimum;
135 watts maximum
Sensitivity: 90dB SPL (2.83V/1 meter)
Adjustments: Tweeter Level (±3dB)
Z4, Z4R, Z4S
Tweeter: 1” (25mm) ber yllium dome,
ferrofluid cooled, pivoting
Woofer: 4” (102mm) ber yllium co ne,
rubber surround, extended pole piece
(Z4), pivoting (Z4R/Z4S)
Frequency Response: 50Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms
minimum
Power Handling: 5 watts minimum;
100 watts maximum
Sensitivity: 90dB SPL (2.83V/1 meter)
Adjustments: Tweeter Level (±3dB) on Z4
only
X4, X4R, X4S
Tweeter: 1” (25mm) silk dome, ferrofluid
cooled, pivoting
Woofer: 4” (102mm) carbon fiber co ne,
rubber surround, pivoting (X4R/X4S)
Frequency Response: 55Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms
minimum
Power Handling: 5 watts minimum;
80 watts maximum
Sensitivity: 90dB SPL (2.83V/1 meter)
Adjustments: Tweeter Level (±3dB) on X4
only
Architectural Series Speaker Performance Specifications
Architectural Series Woofer Performance Specifications
