Specifications:

Cinema Select LCR

Tweeter:

1" (25mm) Silk dome, Ferrofluid-
cooled, shielded magnet

Woofer:

6½" (165mm) Carbon fiber cone,
rubber surround, shielded magnet

Frequency Response:

80Hz – 20kHz ±3dB

Impedance:

8 Ohms nominal; 5 Ohms minimum

Power Handling:

5 watts minimum; 135 Watts maximum

Sensitivity:

90dB SPL (2.83V 1 meter)

Grille Material:

Per forated aluminum

Dimensions (W x H x D): 8¼” x 12

3

/

16

" x 3

7

/

8

"

(210mm x 310mm x 98mm)

Cutout Dim. (W x H):

6

13

/

16

" x 10

11

/

16

" (172mm x 270mm)

Shipping Weight:

5 lbs. (2.3kg) Each

Cinema Select SUR

Tweeter:

Two 1" (25mm) silk domes,
Ferrofluid-cooled

Woofer:

6½" (165mm) Carbon fiber cone,
rubber surround

Frequency Response:

55Hz – 20kHz ± 3dB

Impedance:

8 Ohms nominal; 5 Ohms minimum

Power Handling:

5 watts minimum; 135 Watts maximum

Sensitivity:

90dB SPL (2.83V 1 meter)

Grille Material:

Per forated aluminum

Dimensions (W x H x D): 8¼” x 12

3

/

16

" x 3

7

/

8

"

(210mm x 310mm x 98mm)

Cutout Dim. (W x H):

6

13

/

16

" x 10

11

/

16

" (172mm x 270mm)

Shipping Weight:

10 lbs. (4.5kg) Pair

Sonance Cinema Select

®

speakers bring true cinema

per formance to those with smaller theater rooms.
In fact, earning THX

®

Select cer tification guarantees

that in rooms up to 2,000 cubic feet, Cinema Select
speakers will reproduce film soundtracks just as their
filmmakers intended them to sound.

By incorporating the latest materials and technologies,
Cinema Select speakers per form just as impressively
with music as they do with film soundtracks, while
their paintable aluminum grilles and small footprint
let them practically disappear into the décor.

Sonance Cinema Select speakers establish a formidable
standard of home enter tainment per formance that
makes them ideal for both multi-channel home theater
and music applications, all while effortlessly integrating
into almost any lifestyle.

Features:

• THX

®

Select certification guarantees cinema-quality

performance in rooms up to 2,000 ft

3

.

• Ideal for both home theater and multi-channel

music applications.

• Advanced carbon fiber woofer cones deliver robust,

low-distortion bass in a small footprint that increases
installation options.

Tweeter acoustic back chamber widens and
smoothes high-frequency performance.

• Neodymium woofer magnets increase output and

power handling.

• Low-resonance ¾” MDF baffles.
• Cinema Select LCR has shielded magnets that allow

installation near CRT video displays.

• Cinema Select SUR features a wide-dispersion

monopole design that creates a spacious, enveloping
surround sound environment.

• The RotoLock

®

mounting system makes installation

quick and easy.

• Exclusive new FastMount

®

tabs hold speaker in the

mounting hole during installation, allowing
installer to let go of the speaker to pick-up tools or
other items.

Cinema Select LCR

(left);

Cinema Select SUR

(right)

Sonance Cinema

®

Series

Cinema Select LCR & SUR
