Instructions for the User
34
To fit the pan stand, first align it with the fixing
pin (1) and then lower it into place on the hob,
taking care that it fits over the flame diffuser
ring correctly (2).
Each pan stand will only fit onto its own burner.
To ensure correct positioning, each pan stand
has a different recess (as shown here) which
will fit over the projection on the corresponding
flame diffuser ring.
Take great care to fit the correct pan stand on
each burner. After the pan stand is fitted its feet
must rest on the hob and not be suspended
above it.
Make sure that the pan stands are simply fitted over their burners, and are not
left in a raised or tilted position; if this occurs, repeat the fitting procedure.
WRONG
RIGHT
WRONG
RIGHT
