Instructions for the User
32
6. Description of controls
6.1 The front panel
All the hob's control and monitoring devices are placed together on the front panel.
CONTROL AREA
5 Burner Hob
KNOB OPERATING MODE
To light the flame, press the knob and at the same time turn it anti-clockwise to
the minimum flame symbol .
To adjust the flame, turn the knob to the zone between the maximum and the
minimum settings.
To turn off the burner, turn the knob back to the O position.
BURNER LAYOUT - Key to symbols
Rear left-hand burner Front left-hand burner Middle burner
Rear right-hand burner Front right-hand burner
