Sinclair Electronic Automatic Grommet PG-239 - Manual (Page 22)

WASHERS RACEWAY
Schematic # Part # Description
181 PGR239181 Screws for part 246
239 PGR239239 Hopper box motor
243 PGR239243 Brush pin
244 PGR239244 Threaded pin for holding hopper box
245 PGR239245 Brushes
246 PGR239246 Brush Spacer
247 PGR239247 Acrylic Box Cover
251 PGR239251 Knob for opening the hopper box cover
253 PGR239253 Upper box bearing
270 PGR239270 Mounting studs
291 PGR239291 Knob washer
310 PGR239310 Rear hopper box mounting bracket
313 PGR239313 Hopper box bottom plate
314 PGR239314 Rear hopper box mounting
315 PGR239315 Hopper box housing
341 PGR239341 Acrylic Box Hinge
385 PGR239385 Magnet
