Sunfire OLE-2SF - Manual (Page 16)

System Connections
Zone Control
The most common application
(and default configuration out of
the box) is to use your Olé-2SF as
a Zone controller. Without any
programming you will be able to:
• Select Zone sources
• Adjust Zone volume (with feed-
back)
• Control the AM/FM/SIRIUS tuners
(with RDS and metadata feed-
back)
• Basic control of VIA!migo iPod
cradle (with metadata feedback)
• Adjust Zone bass and treble
CAT-5
ZONE 2 SPEAKERS ZONE 2 Olé-2SF
USE EITHER
CONNECTION
NOTE: The two TP (touchpad)
ports on your Sunfire receiver or
processor are identical.
All programming is stored in the
Olé-2SF, so to reconfigure your
Olé-SF to control the main zone, or
to add source IR control (play/stop/
pause on a CD player, for example),
you will need to connect the Olé-
SF to your PC for programming.
16
