Sony BRC-Z330 - Manual (Page 49)

In
s
ta
llat
ion
a
nd
Conne
c
tio
ns
Installation
49
5
Attach the other end of the wire rope to the material
near the shelf, etc.
Use an M4 or larger outside diameter screw (not
supplied). Attach the wire rope to the material
independent of the shelf, etc. where the ceiling
bracket (B) is attached.
6
Insert the protrusions on the ceiling bracket (A) into
the spaces prepared in the ceiling bracket (B) with
the a hole in the front of the ceiling bracket (A)
aligned with the f hole on the ceiling bracket (B),
and temporarily attach them by turning the ceiling
bracket (A) with the camera clockwise.
M4 or larger diameter screw
Wire rope
(supplied)
Ceiling bracket
(B)
Align.
Ceiling
bracket (A)
