• 9 •
CONTROL PANEL 11.
Charge Rate Selector Switch (Volt/Amp)
Use the Charge Rate selector switch to select the charge rate or engine
starting setting you require.
2A Trickle Charge Rate • – Intended for charging small batteries such as
those commonly used in garden tractors, snow mobiles and motorcycles.
20A Medium, 40A Fast and 65A Rapid Charge Rate
• – Use for charging
automotive, marine and deep-cycle batteries. Not intended for industrial
applications.
225A Engine Start
• – Provides 225 amps for cranking an engine with a
weak or run down battery. Always use in combination with a battery.
Timer
Timer Setting • : The timer allows you to set a specified time for charging,
after the timer expires the charger stops charging your battery. The main
function of the timer is to prevent over charging while allowing a battery
time to obtain a satisfactory charge. To properly set the timer you must
know the size of the battery in ampere hours or reserve capacity in minutes
and the state of charge. It is important that you determine the appropriate
state of charge of your battery as specified in Section 13 and set the timer
accordingly.
Hold
• : This position defeats the timer function, allowing for continuous
operation. Use it when you want to charge more than 2¼ hours. Be sure to
monitor the charging procedure and stop it when the battery is charged. Not
doing so may cause damage to your battery or may cause other personal
property damage or personal injury.
Ammeter
The Ammeter indicates the amount of current, measured in amps, that is being
drawn by the battery. As a battery takes on a charge, it draws less current from
the charger. Correspondingly the meter will show less current being drawn by
the battery. When the current stops decreasing, the battery is charged.
The start area of the meter indicates a high rate of current being drawn from
the charger. When cranking an engine, the meter needle will be at the extreme
right side of the start area.
The 2 amp charge rate may indicate some activity on the meter, although the
meter does not have the resolution to display this low rate.
OPERATING INSTRUCTIONS 12.
Charging
Ensure that all of the charger components are in place and in good working 1.
condition, including the plastic boots on the battery clips.
Connect the battery following the precautions listed in Sections 6 and 7.
2.
Select the appropriate settings for your battery. 3.
Connect the AC power following the precautions listed in Section 8. 4.
Using the Engine Start feature
Your battery charger can be used to jumpstart your car if the battery is low.
Follow these instructions on how to use the ENGINE START feature.
Follow all safety instructions and precautions for charging
your battery. Wear complete eye protection and clothing protection. Charge
your battery in a well-ventilated area.
