• 8 •
Recommended minimum AWG size for extension cord: 8.3
100 feet (30.5 meters) long or less – use an 18 gauge (0.82 mm • 2 )
extension cord.
Over 100 feet (30.5 meters) long – use a 16 gauge (1.31 mm • 2 )
extension cord.
FEATURES 9.
1 2
3
AC POWER 1. (red) LED
CHARGING 2. (yellow) LED
CHARGED 3. (green) LED
Battery Clip Cable Assembly 4.
Ring Terminal Cable Assembly 5.
Quick-Connect Connector 6.
4 5
6
ASSEMBLY iNSTRUCTiONS 10.
Remove all cord wraps and uncoil the cables prior to using the
battery charger.
