PARTS LIST
No. Description Qty. Order No. GM BOM NO.
8.25-424 Bushing 2 8.25-424
IR-BOLT-06-03-10X17.5
8.25-500
Motor Assembly
8.25-501 Motor Hood 1 8.25-501
PL-MCU-XT220
8.25-502 Elevation Motor 1 8.25-502
EL-MO-IS25
8.25-503 Elevation Gear Sleeve 1 8.25-503
EL-MO-JS25-O
8.25-504 Driving Motor 1 8.25-504
EL-MO-B1K-1.2HP-4800RPM
8.25-505 Motor Holder 1 8.25-505
AL-TL-01-118
8.25-506 Driving Belt 1 8.25-506
RU-PB-250J-7
8.25-507 Motor Control Board 1 8.25-507
8.25-508 Elevation Control Board 1 8.25-508
8.25-509 Elevation Support Tube 1 8.25-509
IR-WD-EF-XT220
8.25-510 Elevation Support Tube Cover - Left 1 8.25-510
PL-EFCL-XT220
8.25-511 Motor Bottom Cover 1 8.25-511
PL-MCU-XT220
8.25-512 Deck Frame Side Cover - Left 1 8.25-512
PL-MCSL-XT220
8.25-513 Plastic Clamp - Top 2 8.25-513
PL-AP-002
8.25-514 Plastic Clamp - Bottom 2 8.25-514
PL-AP-003
8.25-515 Elevation Support 2 8.25-515
IR-AP-002
8.25-516 Elevation Support Cap 2 8.25-516
PL-ROC-19.4
8.25-517 Deck Rubber Cushion 2 8.25-517
8.25-518 Rear Vent Cover 1 8.25-518
PL-MCU-XT220
8.25-519 Elevation Support Tube Cover - Right 1 8.25-519
PL-EFCR-XT220
8.25-520 Deck Frame Side Cover - Right 1 8.25-520
PL-MCSR-XT220
8.25-600
Running Deck Assembly
8.25-601 Running Belt 1 8.25-601
RU-RB-1.6X493X2760
8.25-602 Side Rail 2 8.25-602
PL-SRL-XT220
8.25-603 Side Rail End Cap - Left 1 8.25-603
PL-ECL-XT220
8.25-604 Side rail End Cap - Right 1 8.25-604
PL-ECR-XT220
8.25-605 Running Deck 1 8.25-605
WO-RB-1195X652X19
8.25-700
Deck Frame Assembly
8.25-701 Deck Frame 1 8.25-701
IR-WD-RF-XT220
8.25-702 Front Roller Shaft 1 8.25-702
AP-007-04-15X570-IR
8.25-703 Front Roller Tube 1 8.25-703
AP-007-63.5X117
