Assembly – Smooth Fitness Motorized 8.25E User Manual
Page 20
20
8.25E TREADMILL
www.smoothfitness.co.uk
ASSEMBLY
STEP 2:
First connect the Motion Control Wire Middle Section (309) to Motion Control Wire
Lower Section (207) as shown.
Insert the Handlebar (201) into the Upright Tube (301)
（302） and secure using two
M8 x 15mm Bolts (804), Four M8 x 50mm Bolts (805) to Base Frame (401).
804
X2
805
X8
309
207
