ASSEMBLY
STEP 1:
Remove your treadmill from the carton and place it on the floor in an open area.
Connect the Middle Section Computer Wire (308) to the Lower Section Computer Wire (403) and the Middle Section Safety Key
Wire (307) to the Lower Section Safety Key Wire (402). Insert any extra cable length into the Left Upright (301).
Insert the Left and Right Uprights (301)
（302） into the Base Frame (401).
403
402
307
308
