Commercial Cylinders
There are Schlage cylinders suitable for all
commercial applications.
Interchangeable core cylinders offer fast
changeover when keys are lost.
Primus cylinders are recommended where
positive key control is required, such as
airports, hospitals, schools, universities
and research facilities.
Everest keyways (standard) are recommended
for all 21st century key systems because of
their flexibility, stronger keys and patent life.
Classic keyways are used in Schlage’s installed
base of fine 20th century key systems.
C Y L I N D E R S , K E Y S A N D K E Y C O N T R O L
Springs
Top pins
Master pins (as required)
Bottom pins
Side bitting
Drill resistant plug (optional)
5 Finger pins
Cam screw
Cam
Shell
Sidebar
2 Sidebar springs
Finger pin springs
Exploded View - Everest Primus Mortise Cylinder
Authorization Forms 28
Bulk Pack Cylinder Kits 27
Cylinder Choices 5
Cylinders for Schlage Locks 6 - 10
Cylinders for Exit Devices, Alum. Doors 11, 15, 19
Cylinders for Other Manufacturers’ Locks 20, 21
Everest and Classic Comparison 3
Interchangeable Core, Full Size 12 - 15
Interchangeable Core, Small Format 16 - 19
Key Blanks 22, 24, 26
Keyways 23, 25, 26
Multiple Tailpiece Cylinder 27
Primus ID Cards, Sales Aids & Forms 28
Primus Security Levels 29
Service Equipment & Tools 27
Special Cams 20
Specifications 1
Terminology 2
