Schlage CYLINDERS - Manual (Page 12)

Complete Padlock Cylinder Only
Conventional Primus Primus UL Conventional Primus Primus UL
PL1001 PL1741 PL1541
PL1002 PL1742 PL1542
PL1003 PL1743 PL1543
PL2001 PL2741 PL2541
47-410 47-740 47-540
PL2002 PL2742 PL2542
PL2003 PL2743 PL2543
PL3001 PL3741 PL3541
PL3002 PL3742 PL3542
10
C Y L I N D E R S , K E Y S A N D K E Y C O N T R O L
Cabinet Locks and Padlocks
PL-Series Padlocks
CL-Series Cabinet Locks
CL1000 CL2000
Door Drawer
Padlock
Series
PL1000
1 ³⁄₄ ” x 2 ¹⁄₈ ” x ³⁄₄ ”
PL2000
2 ” x 2 ¹⁄₈ ” x ³⁄₄ ”
PL3000
2 ¹⁄₄ ” x 2 ³⁄₈ ” x ⁷⁄₈ ”
⁵⁄₁₆”
⁵⁄₁₆”
⁵⁄₁₆”
³⁄₈”
³⁄₈”
³⁄₈”
⁷⁄₁₆”
⁷⁄₁₆”
1¹⁄₈”
2”
3”
1¹⁄₈”
2”
3”
1¹⁄₈”
2”
³⁄₄”
³⁄₄”
³⁄₄”
³⁄₄”
³⁄₄”
³⁄₄”
¹⁵⁄₁₆”
¹⁵⁄₁₆”
Shackle Dimensions
A B C
HA
RDENED
C
B
A
Complete Lock Cylinder Only
Application Bolt Conventional Primus Primus UL Conventional Primus Primus UL
Door
1” (std) CL1000PB CL1740PB CL1540PB
20-172 20-772 20-572
1 / 2 ” CL1009PB CL1749PB CL1549PB
Drawer
1 / 2 ” (std) CL2000PB CL2740PB CL2540PB
20-174 20-774 20-574
3 / 4 ” CL2009PB CL2749PB CL2549PB
Available 606 and 626 finish.
Everest C123 keyway standard.
Available 606 finish only.
Everest C123 keyway standard.
