5
Specifications
ITEM D4RS/D4WRS D8RS/D8WRS 16RS/D16WRS
Video
Input
Channel, Input Level 4CH / 8CH / 16CH Composite, 1.0Vp-p, 75ohm
Signal Format NTSC/PAL
Video Loss Check Yes
Output
VGA 1 VGA (1024x768, 1280x1024)
CVBS 1 BNC 1 BNC 1 BNC
SPOT - 1 BNC 1 BNC
Audio
Input & Output 4 CH Line input & 1 CH Line output
Audio Codec G.711
Sensor/
Alarm
Sensor Input - 4 (NC / NO Selectable)
Alarm Out - 1 Alarm Out by Sensor, Motion and
Video Loss
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Resolution
NTSC
D1 120fps 120fps 120fps
Half D1 120fps 240fps 240fps
CIF 120fps 240fps 480fps
PAL
D1 100fps 100fps 100fps
Half D1 100fps 200fps 200fps
CIF 100fps 200fps 400fps
Recording quality grade LEVEL1 (L) ~ LEVEL5 (H)
Recording Mode Continuous/Schedule/ Motion/Manual/Sensor
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution
Yes
Pre Recording 1 fps for up to 20minutes before an event
Post Recording 10 seconds to 3 minutes after an event
Display Frame Rate (/Sec) NTSC: 30fps/CH, 60 fields / PAL: 25fps/CH, 50 fields
Playback
Multi-Decoding 1, 4 1, 4, 8 1, 4, 9, 16
Playback
Speed
Single channel ×2, 4, 8, 16, 32, 64
Multi-channels Ч2, 4, 8, 16, 32 Ч2, 4, 8, 16 Ч2, 4, 8
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA
Capacity of 1 HDD
D4RS/D4WRS: Max. 1 TB
D8RS/D8WRS/D16RS/D16WRS: Max. 2 TB
Internal HDD No. 1
File system NaFS
