Dimensions
Design Data
SLANT/FIN CORPORATION, Greenvale, N.Y. 11548 • Phone: (516) 484-2600
FAX: (516) 484-5921 • Canada: Slant/Fin LTD/LTEE , Mississauga, Ontario
www.slantfin.com
©Slant/Fin Corp. 1991. Printed in the U.S.A. 1003. Publication No. C-10-MOS
Model No.
LDZO-600-2-5 21 5 ⁄
8
8 7 ⁄
32
8 34 3 ⁄
8
4'4"
LDZO-750-2-6 25 9 29 ⁄
32
8 37 3 ⁄
4
4'4"
LDZO-850-2-7 28 3 ⁄
8
11 19 ⁄
32
9 41 1 ⁄
8
4'4"
LDZO-900-3-5 21 5 ⁄
8
8 7 ⁄
32
8 34 3 ⁄
8
6'7"
LDZO-1100-3-6 25 9 29 ⁄
32
8 37 3 ⁄
4
6'7"
LDZO-1300-3-7 28 3 ⁄
8
11 19 ⁄
32
9 41 1 ⁄
8
6'7"
LDZO-1700-4-7 28 3 ⁄
8
11 19 ⁄
32
9 41 1 ⁄
8
8'10"
LDZO-2100-5-7 28 3 ⁄
8
11 19 ⁄
32
9 41 1 ⁄
8
11'1"
A L B C D
Max. ASME Working Pressure: 15 psi
Power Requirements: 120 V/60 HZ,
6.0 amps per module
* Inches, except “L” which is feet/inches.
* CHECK LOCAL CODES TO VERIFY COMPLIANCE
Dimensions*
