Components
Getting to Know Your Printer
The maximum paper capacity with all options installed is 1800 sheets of 20 lb. (75 gsm) paper.
The label in each paper tray indicates the maximum stacking capacity for certain paper types.
Rear View
Data I/O connector settings can be configured via the Operator Panel’s Interface Menu. There
are settings for each of the I/O ports including IEEE-1284, USB2, Serial RS-232, and Ethernet.
No. Name
1 USB 2
2 Serial RS-232
3 Ethernet 10/100 Base-Tx
4 IEEE 1284 Parallel
5 Power Receptacle
6 Optional Duplex Module
7 Rear Cover, access to Fuser
8 Offset Catch Tray Rear Cover
Tray 1 Tray 2
1
2
3
4
5
6
7
8
