Page 11
EVB-EMC2101 User Manual
SMSC EMC2101
Revision 1.5 (12-13-06)
11
NOTE: Only one jumper is to be installed on JP11 and a minimum of one jumper must be installed
for the device to operate.
3.10
Other Sensor Features
Other features such as Ideality Factor Configuration, Conversion Rate, Digital Filtering, Look-up Table
Functionality, and Standby Mode can be controlled with EMC2101 registers. See the datasheet register
description for details.
Table 3.6 ALERT Pull-up Resistors - SMBus/FAN MODE
JUMPER
NAME
OPEN
SHORT
JP11
33k
NA
Auto load via EEPROM -
Initial FAN 0% Duty Cycle
18k
NA
Auto load via EEPROM -
Initial FAN 100% Duty Cycle
10k
NA
Host load via SMBus -
initial FAN 0% Duty Cycle
5.6k
NA
Host load via SMBus -
initial FAN 100% Duty Cycle
