OPERATION
EC72 03/08 Operation Section 4-3
© 2008 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
EC72
Horsepower Required 30 Min. HP
Cutting Capacity (Max.) 1”
Cutting Height 1” Min.
Safety Deflector Std. Front, Metal Band Rear
Cutting Width 72”
Overall Length 128
Weight (Approx.) 675 lbs
Hitch CAT I (lift)
Blade Carrier Pan
Blade Tip Speed (FPM) 14,930
Gearbox Rating:
540 RPM 60 HP*
Output Shaft Diameter 1-9/16”
Driveline Size Cat 3
Deck Thickness 11 Ga.
Side Skirt 6-7/8”
Transport Width 79”
*Ratings based on actual field performance.
The Mower is designed for certain mowing applications and is rated to cut up to a specific
size vegetation (see Mower Standard Equipment and Specifications). DO NOT use this
mower to cut vegetation above the Mower’s rated capacity or to cut any type of non-
vegetative material. Only operate this Mower on a properly sized and equipped Tractor. Operating this Mower
in an application for which it is not designed and/or operating the Mower with the wrong size Tractor can cause
Mower component damage and equipment failure resulting in possible serious injury or death.
(SGM-14)
