7 TP 400-2227-00-RT-S
Hood, Drag Stake & Bolo Tines
1 1935048 3 NUT-Bi-Way Lock, 5/16-18
2 1716700 1 HANDLE GRIP, Black
3 1917356 5 LOCKWASHER-Spring, 5/16”
4 1921958 12 BOLT-Hex Hd, 1 /4-20 x 1 /2”
5 1921971 1 BOLT-Hex Hd, 3/8-16 x 1-3/4”
6 1916950 1 LOCKNUT-Hex, 3/8-16
7 928372 10 NUT-Keps, 1/4-20
8 1719046 8 TlNE-Bolo, Right Side
9 1719047 8 TlNE-Bolo, Left Side
10 1719048 2 HOLDER-Bolo Tine, Both Sides
11 1719049 2 HUB-Tine
12 1921333 2 BOLT-HHCS, 5/16-18 x 3”, Grade 5
13 1719050 1 TILLER DRIVE TRANSMISSION, Complete
14 1960590 1 BOLT-Hex Hd, 5/16-18 x 3”
15 1916955 10 WASHER-Flat, 1/4”
16 1719021 16 BOLT, 8mm x 30mm
17 1719025 24 NUT, 8mm x 1.25mm
18 1719053 2 NUT, 20mm x 1.50mm
19 1719054 2 SIDE SHIELD-Hood, Both Sides
20 1719055 1 HOOD-Tiller
21 1719056 1 BRACKET-Depth Regulator
22 1719057 1 BRACKET-Hood, Right Side
23 1719058 1 BRACKET-Hood, Left Side
24 1716742 1 DETENT PIN, 5/16-18 x 1”, Drag Stake
25 1716743 1 KNOB-T-Handle, Drag Stake
26 1716746 1 LEVER-Drag Stake
27 1719059 2 EXTENSlON-Hood Flap, Both Sides
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693207 821RT, 8HP Rear Tine Tiller
