Handlebar assembly – Simplicity 821RT User Manual
Page 5
Handlebar Assembly
3
TP 400-2227-00-RT-S
1
1716699
2
HANDLE GRIP-Drive Control Lever
2
1718994
1
KNOB-Black, Direction Shift Rod
3
1718995
3
WASHER
4
1921961
1
BOLT-Hex Hd, 1/4-20 x 1-1/4”
5
928372
1
NUT-Keps, 1/4-20
6
1718997
1
PIN-Swivel Lock
7
1718998
1
TILT LEVER
8
1718999
3
PLASTIC PIVOT
9
1719000
1
SPRING-Tilt Lever
10
1719001
1
SPRING-Swivel Lock
11
1719002
4
RUBBER GROMMET
12
1719003
1
CABLE END-Swivel, Threaded
13
1719004
1
PIN-Latch, Tilt Lever
14
1719005
1
BASE LOCK PLATE
15
1719006
2
SHEATH END-Cable
16
1719007
1
CABLE LOCK HOLDER
17
1719008
1
SHEATH END-Lower
18
1719009
1
KNOB-Green, Tine Engage Rod
19
1719010
1
FREE WHEEL LEVER
20
1719011
1
BUSHING-Free Wheel Lever
21
1716705
2
TILT FRICTION PAD
22
1719012
2
U-BOLT
23
1719013
1
CABLE ASSEMBLY-Swivel Lever
24
1719014
1
CABLE CLAMP
25
1719015
1
KNOB-Orange, Gear Shift Rod
26
1719016
1
HANDLEBAR BASE-Lower
27
1719017
1
HANDLEBAR STEM
28
1719018
1
HANDLEBAR BASE-Upper
29
1719019
1
BOLT-Cable Clamp, 6mm x 22mm
30
1719020
2
NUT, 8mm
31
1719021
2
BOLT, 8mm x 30mm
32
1719022
2
BOLT, 8mm
33
1719023
1
BOLT, 8mm x 45mm
34
1719024
1
BOLT, 5mm x 10mm
35
1719025
2
NUT, 8mm x 1.25mm
36
1719026
7
LOCKNUT, 8mm
37
1719027
1
LOCKNUT, 6mm
38
1719028
4
WASHER-Flat, 8mm
39
1719029
3
WASHER-Wavy, 8mm
40
1719030
2
WASHER-Spring, 8mm
41
1719031
1
WASHER-Flat, 6mm
42
1719032
3
PIN-Hair
43
1719033
1
BALL-Cable Lock, 3/16”
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
Ref Nos 44-64 listed on following page.
The above parts group applies to the following Mfg. Nos.:
1693207 821RT, 8HP Rear Tine Tiller
