Shifting mechanism – Simplicity 821RT User Manual
Page 13
11
TP 400-2227-00-RT-S
Shifting Mechanism
1
1935048
4
NUT-Bi-Way Lock, 5/16-18
2
1921221
1
BOLT-Hex Hd, 5/16-18 x 1-1/2”, Grade 5
3
1917356
2
LOCKWASHER-Spring, 5/16”
4
1921977
4
BOLT-Hex Hd, 5/16”-18 x 1-1/4”, Grade 5
5
1716801
1
MOUNTING BAR-Shift Mechanism
6
1716802
1
SPRlNG-ldler Arm
7
1716803
1
PULLEY-Forward Idler
8
1716804
1
IDLER ARM-Forward
9
1716702
1
LINK PlN-Forward
10
1716703
1
COTTER PIN
11
1921978
1
BOLT-Hex Hd, 5/16-18 x 2, Grade 5
12
1716704
1
BUSHlNG-Pivot, 5/16”
13
1716780
4
BOLT-Hex Flange Hd, 5/16-18 x 3/4”, Grade 5
14
1921332
2
BOLT-Hex Hd, 5/16-18 x 3/4”
15
1916950
1
NUT-Hex, 3/8-16
16
1718872
1
SUPPORT BRACKET-Belt Cover
17
1718874
1
COVER-Transmission Wheel Housing
18
1719060
1
MOUNTING BAR-Shift Mechanism, w/Forward Belt Guides
19
1719061
1
PLATE-Shift Mech Mounting Bar
20
1719062
1
BELT COVER
21
1716728
1
YOKE-Cable
22
1917372
4
NUT-Non Locking, 5/16-18
23
1719037
1
CABLE ASSEMBLY-Drive Control Lever
24
1719063
1
C-CLAMP, Drive Control Cable
25
1719064
2
MOUNTING BRACKET-Belt Cover
26
1716731
1
BOLT-Hex Hd, 5mm x 0.8mm x 10mm
27
1716732
1
NUT-Nyloc, 5mm x 0.8mm
28
1924940
3
WASHER-Flat, 3/8”
29
1960044
4
WASHER-Flat, 5/16”
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693207 821RT, 8HP Rear Tine Tiller
