Simplicity 821RT - Manual (Page 11)

9 TP 400-2227-00-RT-S
Engine Mounting, Belts & Wheels
1 1935048 8 NUT-Bi-Way Lock, 5/16-18
2 * 1 ENGINE-Briggs & Stratton, 8HP
3 1716767 1 GUIDE-Belt, Forward
4 1718544 1 BELT-Forward
5 1718887 1 WHEEL/TIRE ASSEMBLY, Left Side
5 1718888 1 WHEEL/TIRE ASSEMBLY, Right Side
6 1921977 4 BOLT-Hex Hd, 5/16-18 x 1-1/4”
7 1718890 1 BUSHING
8 1716780 1 BOLT-Hex Flange Hd, 5/16-18 x 3/4”, Grade 5
9 1718891 8 BOLT-Lug,1/2-20 x 3/4”
10 1718892 2 ADAPTER-Wheel
11 1921333 8 BOLT-HHCS, 5/16-18 x 3”, Grade 5
12 1719065 1 ARM-Forward/Reverse Shift
13 1718894 1 BOLT-Hex Hd, 6mm x 14mm
14 1716715 1 BOLT-Hex Hd, 8mm x 16mm
15 1718895 2 BOLT-Hex Hd, 8mm x 22mm
16 1719025 4 NUT, 8mm x 1.25mm
17 1718873 8 NUT, 12mm x 1.25mm
18 1719029 2 WASHER-Wavy, 8mm
19 1718896 8 WASHER,12mm
20 1960384 1 BOLT-Hex Hd, 7/16-20NF x 1 “, Grade 5
21 1718898 1 WEIGHT CASTING
22 1718899 1 SPACER-Engine Pulley, Short, Engine Side
23 1718900 1 SPACER-Engine Pulley, Long
24 1718901 1 PULLEY-Drive, Engine Forward
25 1718902 1 PULLEY-Drive, Transmission
26 1718903 1 KEY-Half Moon
27 1718904 2 SETSCREW
28 1718905 1 BRACKET-Motor Mount, Left
29 1718906 1 BRACKET-Motor Mount, Right
30 1718907 1 BUMPER GUARD
31 1960044 2 WASHER-Flat, 5/16”
32 1919384 1 WASHER-Flat, 7/16”
33 1918199 1 WASHER-Spring Loc, 7/16”
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
*See your local Briggs & Stratton distributor for service parts.
The above parts group applies to the following Mfg. Nos.:
1693207 821RT, 8HP Rear Tine Tiller
