Transmission housing – Simplicity 821RT User Manual
Page 15
1693207 821RT, 8HP Rear Tine Tiller
13
TP 400-2227-00-RT-S
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
Transmission Housing
1
1718860
1
WHEEL DRlVE TRANSMlSSlON-Complete, Bolt-On
2
1718861
1
GASKET-Housing, Front
3
1718862
1
GASKET-Housing, Top
5
1718863
1
GEAR-Reverse Jack Shift
6
1719085
1
ARM-PTO Engage
7
1718864
1
STOP PLATE-Forward/Reverse
8
1719086
1
BUSHING
9
1718865
1
PIN-Dowel, 6mm x 16mm
10
1718866
1
COVER- Rear Transmission Housing
11
1718867
1
STUB SHAFT, Jack Shift
12
1718868
1
BOLT, Drain Plug
13
1718869
1
KEEPER
14
1719087
1
BOLT, 6mm x 16mm
15
1719021
2
BOLT, 8mm x 30mm
16
1719023
3
BOLT, 8mm x 45mm
17
1719025
3
NUT, 8mm x 1.25mm
18
1718873
2
NUT, 12mm x 1.25mm
19
1719088
1
WASHER, 6mm
20
1719029
5
WASHER-Wavy, 8mm
21
1719074
1
SEAL-N/1/2 Arm, 12mm x 19mm x 5mm
22
1709089
1
SEAL-PTO Engage Arm
23
1718876
1
SNAP RING-C Clip
24
1718877
1
LOCKNUT, 8mm
25
1718878
4
STUD, 8mm x 20mm
26
1718879
2
STUD, 12mm x 30mm
27
1718880
1
STUD, 8mm x 45mm
28
1718881
1
STUD, 8mm
29
1718882
1
DIP STICK, Plastic
30
1718883
1
O-RING, Dip Stick
31
1718884
2
WASHER-Flat,12mm
32
1718885
1
WASHER-Nylon, Drain Plug
33
1718886
1
SEAL
