Sennheiser 502011 User Manual
Page 32
29
Additional technical information
Function of the treble boost control
By means of the transmitter’s steplessly adjustable treble boost
control
, the audio signal is boosted as shown in the diagram.
The treble boost control
allows you to select one of the curves
shown in the diagram below.
̈
Use a screwdriver to turn the treble
boost control
to the left or right
until the sound can be heard very
well.
The position “0” corresponds to a
minimum boost, the position “MAX”
corresponds to a maximum boost, and
the control is factory-preset to the
medium position.
G
10
0.1
1
10
20
dB
kHz
“MAX”
“0”
Factory preset
