Connecting the transmitter to a sound source – Sennheiser 502011 User Manual
Page 10
7
Putting the Set 840 S system into operation
Connecting the transmitter to a sound source
̈
Switch your sound source (e.g. TV) off before connecting
the transmitter.
̈
Plug one end of the connection cable
J
into the blue
socket
̈
Check the available connection possibilities of your
sound source (e.g. TV):
̈
Connect the transmitter as described in the corre-
sponding
chapter , ,
or .
Connection possibility Name of connection possibility
Headphone socket
RCA socket
SCART socket
(SCART adapter included with the
EU version)
What if your sound source doesn’t have any of these
connection possibilities?
MKE 800 TV-N external
microphone
(included with the US version)
If possible, use the SCART connection
.
SCART adapter and microphone are also available as
accessories (see page 30).
E
J
A
B
L
R
C
D
A
B
C
D
C
