• 10 •
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
The measured current is
much lower than what was
selected.
The charger reached the
maximum voltage and is
reducing the current.
No problem, this is a normal
condition.
BEFORE RETURNING FOR REPAIRS 14.
When a charging problem arises, make certain that the battery is capable 14.1
of accepting a normal charge. Use a good battery to double check all
connections and the AC outlet for a full 120-volts.
When an UNKNOWN OPERATING PROBLEM arises, please read the
14.2
complete manual and call the customer service number for information
that will usually eliminate the need for return.
If the above solutions do not eliminate the problem or for information about troubleshooting
or replacement parts, call toll-free from anywhere in the U.S.A.
1-800-621-5485
7:00 am to 5:00 pm Central Time Monday thru Friday
SPECIFICATIONS 15.
Electrical
Nominal Operating Voltage (VAC) 120
Input Voltage Range (VAC) 120 ± 10%
Input Current (A max) 15 A
Output Power (W) 1200
Output Current (A max) 25
Output Voltage (VDC max. / maintain) 61.6 / 52.8
Mechanical
Case Steel with Baked Enamel Finish
Dimensions (inches) 11 L x 9½ W x 10 ¼ H
Weight 40 lbs
Connections
AC Power Input Cable 14 Gauge 9’ with NEMA 5.15 Plug
DC Power Output Adapters 8 Gauge 6’ with Polarized 50 Amp Quick
Connect Connector
