• 6 •
Recommended minimum AWG size for extension cord: 7.3
25 feet long or less - use a 12 gauge extension cord. •
25 feet to 50 feet long - use a 10 gauge extension cord. •
Over 50 feet long - not recommended. •
FEATURES 8.
ON/OFF Switch 1.
Charging/Charged LED 2.
Quick-Connect Connector 3.
1
3
2
OPERATING INSTRUCTIONS 9.
Automatic Temperature Compensation
The charger adjusts the maximum charge voltage and maximum maintain
voltage based on the ambient air temperature. This permits optimum
charging and safety.
Thermal Runaway
The charger automatically reduces the current if it detects the battery may
be getting too hot. This is a safety precaution.
Charging
Ensure that all of the charger components are in place and in good 1.
working condition.
Connect the battery to the charger by connecting the quick-connect
2.
connector on the charger output cable to the quick-connect connector
on the battery.
Connect the AC power following the precautions listed in Section 7.
3.
Switch the power switch to the ON position to turn the charger on. 4.
