1-43 (E)
BKP-7933
1-9-5. Modification of RCP-730/731
Required Parts
Description
Sony P/N
Q'ty
Resistor, Chip Metal 0
Z
1-216-295-11
3
Resistor, Chip Metal 82
Z
1-216-625-11
1
Modification Procedure (SW-893 Board)
1.
Remove soldering of R1, R2, R3 and R12.
2.
Connect metal resistors 0
Z to the soldering land of R4, R6 and R7 by soldering.
3.
Connect metal resistors 82
Z to the soldering land of R5 by soldering.
Setting Switch on MPU-92 Board
S4-7/MPU-79 board
→
ON
1-9. Modification of RCP
