1-6 (E)

BKP-7933

1-6. Connection

1-6-1. Connection Connector/Cable

Connection made with the connector panel during installation or service, should be made with the
connectors/complete assemblies specified in the following list, or equivalent parts.

Connector Name

Connection Connectors

Conection Cable

REMOTE S-BUS

BNC(75

)

BELDEN 8281

1-569-370-12

I/O PORT

D-sub 50P, Male
1-566-358-11

D-sub for connector metal plating shell 50P
1-563-379-11

1: The BNC connector (T bridge) is available to connect the BELDEN 8281 cables.

BNC connector (T bridge): 1-764-805-11

2: The plug needs the following solderless contacts.

AWG#18 to #22: 1-566-493-21
AWG#22 to #24: 1-564-774-11
AWG#24 to #30: 1-564-775-11
