airPoint™ Nexus User Configuration Guide
i n t e l l i g e n t w i r e l e s s p l a t f o r m
Figure 5-5 Profile Manager
Table 5-3 Profile Manager Menu Items
5.2.1 Save Profile
Follow the steps below to save the current configuration to a profile:
1. Select a profile name from ‘Save As’:
2. Enter a description of the profile.
3. Click the ‘Save Profile’ button to apply changes.
Note: Existing configuration parameters in the selected profile name will be replaced with current
configuration parameters.
Page Item Descriptions
Save As: Select which profile name to save for the current configuration
Profile Description: Specify a description for the profile to be saved.
Save Profile button Click to save current profile
Change Profile To: Select which profile to load as current configuration
Profile Description: Description for profile to be loaded.
Load Profile button Click to Load a specified profile
Select Profile: Choose a profile to schedule
