airPoint™ Nexus User Configuration Guide
i n t e l l i g e n t w i r e l e s s p l a t f o r m
Table 2-1 Description of Parameters
2.2. Web GUI Administrator Password Change
By default the administrator password is smartBridges (case sensitive).
Follow the steps below to change the Administrator password.
1. Click on the ’Tools | User Manager’ drop down menu in the navigation menu bar. An
’Administrator Password change’ GUI will appear.
2. Enter the fields for ’Old Password’, ’new Authentication Password’ and ’Confirm new
Authentication Password’.
3. Click on the ’Apply Changes’ button to change the password.
Figure 2-4 Administrator password change
Page Item Descriptions
IP Address Editable Ethernet IP Address.
IP Mask Editable Ethernet IP subnet Mask
Gateway Editable Gateway IP address. Ethernet
Configuration
DHCP Editable DHCP status Disabled / Enabled
User can enable DHCP by ticking the check box to obtain
an IP address from the network DHCP server
SSID Device SSID.
Channel
Device operation channel.
Association Table Shows the Associated list of clients
Wireless
Configuration
Maximum Wireless
Throughput Maximum Wireless Throughput in kbps
ETH A MAC Address Ethernet A (wired side) MAC address.
Display only
ETH B MAC Address Ethernet B (wired side) MAC address.
Display only
Port Information
Radio MAC Address Radio MAC address.
Display only
Security
Security Mode
Allows user to select the Security Mode and configure it.
Operational Mode
Device operational
mode Current device operational mode: airPoint Bridge or
airPoint Router (future release).
