SPEED DOME CAMERA User’s Manual 44 SPEED DOME CAMERA User’s Manual 45
Camera Setting
① Focus & Zoom
White Balance ATW
③ Exposure
④ Back Light USER
AGC Medium
SSNR Medium
⑦ Day & Night
⑧ Others
Main Menu
① Camera Setting
② Sequence Setting
③ P/T Setting
④ OSD Setting
⑤ Alarm Setting
⑥ Initialize
Status
➡
➡
4.4 User Area Setting
▶ Main Menu/Camera Setting/Back Light/User
You can selectively choose a screen area to see objects within
the area more clearly than others.
Four-direction Joystick Controls :
- Moving the joystick in all four directions—upward,
downward, left, and right—adjusts the location and size
of a selected area.
Zoom Control :
- Zoom Tele : Enlarges the size of a selected area.
- Zoom Wide : Reduces the size of a selected area.
↑:Up↓:Down ←:Left →:Right
W:Decrease T:Increase
Camera Setting
① Focus & Zoom
White Balance ATW
③ Exposure
④ Back Light OFF
AGC Medium
SSNR Medium
⑦ Day & Night
⑧ Others
Main Menu
① Camera Setting
② Sequence Setting
③ P/T Setting
④ OSD Setting
⑤ Alarm Setting
⑥ Initialize
Status
➡
AGC (Automatic Gain Control) adjusts the camera’s gain
control and the screen brightness if the camera has captured
an object under low-light conditions.
The Off, Low, Medium, High, and Manual modes are available.
5. AGC
▶ Main Menu/Camera Setting/AGC
Functional Description Functional Description
