3

6901-100015 <01>

1

Determine the Bolt diameter required — [17] / [21], [18] / [22], [19] / [23], or [20]/ [24] — by threading each size into the back of
the TV. Stop immediately if you encounter any resistance.

1-1: TV with flat back

1-2: TV with curved back or obstruction

[05]

M4 x 12mm

M5 x 12mm

M6 x 12mm

M8 x 16mm

[31]

[26]

[18]

[31]

[25]

[17]

[32]

[27]

[19]

[32]

[28]

[20]

M4 x 30mm

M6 x 35mm

M8 x 40mm

M5 x 30mm

[31] [26] [22]

[31] [25] [21]

[32] [27] [23]

[32] [28] [24]

[31]

[31]

[—]

[—]

[05]

[29]

[29]

[30]

[30]

4x

1-1

1-2
