Basic connecting methods

To view an image projected on the video presenter
through a PC monitor or a projector

• Set the resolution mode of the main unit to the maximum resolution of the external device connected.

To view an image on a TV screen or a monitor
while listening to the sound from a microphone

• The resolution of the TV output is much lower than the VGA output,

so please use it for monitoring or recording.

• Microphone is not supplied. Use one purchased from an audio shop.
• When a microphone is used, the image and sound are produced simultaneously through the projector.

Thus it can be very useful for a demonstration or an exhibition.

Connect to the VGA input terminal

PC monitor,

projector, etc.

TV, monitor, projector, etc.

Yellew

Connect to the audio
input terminal

Connect to the video
input terminal

White

Red

Video Presenter
