Page 9

7
TP-400-2033-00-RT-S
Engine Mounting, Belts & Wheels
1
1917372
2
NUT, 5/16”-18
2
1960044
3
WASHER, Flat, 5/16”
3
1716784
1
BELT COVER
4
1716773
1
WHEEL, Tire Assembly, Left — Model 516RT Only
4
1716775
1
WHEEL, Tire Assembly, Right — Model 516RT Only
5
1716782
2
SCREW, Soc Hd, 1/4”-20 x 2” — Model 516RT Only
6
1716781
2
SPRING — Model 516RT Only
7
1960151
2
WASHER, 1/4” ID — Model 516RT Only
8
1716779
2
SNAP RING — Model 516RT Only
9
1716777
2
KNOB, Wheel Lockout — Model 516RT Only
10
928372
2
NUT, Keps, 1/4”-20 — Model 516RT Only
11
1716778
1
LOCKOUT, Set of 2 — Model 516RT Only
12
1716772
1
WHEEL, Tire Assembly, Left — Model 413RT Only
12
1716774
1
WHEEL, Tire Assembly, Right — Model 413RT Only
13
1716776
2
LOCKPIN — Model 413RT Only
14
960164
1
WASHER, Flat, 11/16” ID
15
1716771
1
KEY, 3/16” x 1”
16
1716768
1
PULLEY, Transmission — Model 413RT Only
16
1716769
1
PULLEY, Transmission — Model 516RT Only
17
1716770
1
WASHER
18
1917356
9
LOCKWASHER, Spring, 5/16” (Qty. 6 on Model 413RT)
19
1921515
2
BOLT, Hex Hd, 5/16”-24 x 3/4”, Grade 5
20
1960470
4
SCREW, Soc Hd, 5/16”-18 x 1-1/4”
21
1716753
1
BRACKET, Engine Mount, Left Side
22
1716754
1
GUARD, Lower Pulley
23
1716780
5
BOLT, Hex Flange Hd, 5/16”, 18 x 3/4”
24
1716783
1
BUMPER GUARD
25
1916965
2
LOCKWASHER, Spring, 3/8”
26
1921210
2
BOLT, Hex Hd, 3/8”-16 x 1”, Grade 5
27
1716752
1
BRACKET, Engine Mount, Right Side
28
1716767
1
BELT GUIDE, Forward
29
1922127
4
SCREW, Hex Hd, 5/16”-18x 1-3/4”
30
1716756
1
SCREW, Hex Hd, 5/16”-24 x 1/2” — Model 516RT Only
31
1716755
1
BELT GUIDE, Reverse — Model 516RT Only
32
*
1
ENGINE, 3.5HP, Model 413RT
32
*
1
ENGINE, 5HP, Model 516RT
33
1716758
1
SET SCREW, 1/4”-20 x 1/4” — Model 516RT Only
34
905121
1
KEY, Woodruff, #5 — Model 516RT Only
35
1716757
1
PULLEY, Engine Reverse — Model 516RT Only
36
1716761
1
PULLEY, Belt Guide, V-Groove — Model 516RT Only
37
1716760
1
BOLT, Hex Hd, 5/16”-24 x 1-1/2” — Model 516RT Only
38
1716759
1
BELT, Reverse — Model 516RT Only
39
1716765
1
BELT, Forward — Model 413RT Only
39
1716766
1
BELT, Forward — Model 516RT Only
40
1716762
1
SPACER, Engine Pulley
41
1716763
1
KEY, 3/16” x 1-1/2”
42
1716764
1
PULLEY, Engine Forward
43
1921978
2
BOLT, Hex, 5/16”-18 x 2”, Grade 5
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
* See your local Briggs & Stratton distributor for service parts.
The above parts group applies to the following Mfg. Nos.:
1692876 413RT, 3.5HP Rear Tine Tiller
1692877 516RT, 5HP Rear Tine Tiller
