Transmission housing – Simplicity 516RT User Manual
Page 13
1692876 413RT, 3.5HP Rear Tine Tiller
1692877 516RT, 5HP Rear Tine Tiller
11
TP-400-2033-00-RT-S
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
* Not shown as a kit in illustration.
The above parts group applies to the following Mfg. Nos.:
Transmission Housing
1
1716787
1
TRANSMISSION ASSEMBLY — Model 413RT Only
(Complete with all gears, shafts, seals, etc.)
1
1716788
1
TRANSMISSION ASSEMBLY — Model 516RT Only
(Complete with all gears, shafts, seals, etc.)
2
1716780
8
BOLT, Hex Flange Hd, 5/16”-18 x 3/4”, Grade 5
(Tiller Housing & Transmission Cover)
3
1716789
2
GASKET, Tiller Housing & Transmission Cover
4
1716790
2
PIPE PLUG, Soc Hd, 1/4”-18, Oil Level
5
1716791
4
SEAL, Tiller Housing
6
1716794
1
PLUG, Oil Fill
7
1716798
3
BOLT, Hex Flange Hd, 1/4”-20 x 3/4”
8
1716797
1
OIL SEAL, Drive Shaft
9
1716796
1
CAP, Front Bearing
10
1716792
2
GASKET, Front Rear Bearing Cap
11
1716793
1
CAP, Rear Bearing
12
1716795
3
BOLT, Hex Flange Hd, 1/4”-20 x 7/8”
*
1716799
1
KIT, Oil Seal Gasket, (Includes Ref. Nos. 3, 5, 8 & 10).
