Simplicity 516RT - Manual (Page 15)

1692876 413RT, 3.5HP Rear Tine Tiller
1692877 516RT, 5HP Rear Tine Tiller
13 TP-400-2033-00-RT-S
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
Transmission Assembly
1 1716793 1 CAP, Rear Bearing
2 1716825 1 SHIM SET, Rear Bearing Cap (includes the following)
2 1716826 SHIM, 1.750 OD x .062” thick, (as req’d.)
2 1716827 SHIM, 1.750 OD x .030” thick, (as req’d.)
2 1716828 SHIM, 1.750 OD x .015” thick, (as req’d.)
2 1716829 SHIM, 1.750 OD x .010” thick, (as req’d.)
3 1716810 2 BEARING, Tapered, (Includes Cone & Race)
4 1716824 4 SPACER, 1.250” x 1.000” x .062” thick
5 1716816 4 BUSHING
6 1716815 4 SHIM SET, Axle Spacer Kit (includes the following)
6 1716817 SHIM, 1.375 OD x .062” thick, (as req’d.)
6 1716818 SHIM, 1.375 OD x .030” thick, (as req’d.)
6 1716819 SHIM, 1.375 OD x .015” thick, (as req’d.)
6 1716820 SHIM, 1.375 OD x .010” thick, (as req’d.)
7 1716830 4 SNAP RING, Retainer, Internal
8 1716791 4 SEAL, Tiller Housing
9 1716809 1 MAIN DRIVE SHAFT
10 1716821 2 SNAP RING, Retainer, External
11 1716797 1 OIL SEAL, Drive Shaft
12 1716814 1 GEAR, Worm, Wheel Shaft
13 1716811 1 WHEEL SHAFT ASSEMBLY, Lockpin — Model 413RT Only
13 1716812 1 WHEEL SHAFT ASSEMBLY, Lockout — Model 516RT Only
14 1716813 2 KEY, 1/4”x 1”
15 1716823 1 GEAR, Worm, Tiller Shaft
16 1716822 1 TILLER SHAFT ASSEMBLY
