Handles & controls – Simplicity 516RT User Manual
Page 5
3
TP-400-2033-00-RT-S
Handles & Controls
1
1716699
2
HANDLE GRIP, Drive Control Lever
2
1716721
1
LEVER, Drive Control
3
1716700
2
HANDLE GRIP, Black
4
1716718
1
ASSEMBLY, Main Handlebar
5
1716722
1
BRACKET, Drive Control Lever, Right
6
1716732
4
NUT, Nyloc, 5mm x 0.8mm
7
1716723
1
BRACKET, Drive Control Lever, Left
8
1716720
1
SPRING, Forward Cable Adjust
9
1716709
2
CLAMP, Handlebar Tilt
10
1917372
5
NUT, 5/16”-18 (Qty. 4 on Model 413RT)
11
920438
4
NUT, Jam, 5/16”-24 (Qty. 2 on Model 413RT)
12
1716726
2
CABLE ASSEMBLY, Control Engage (Qty. 1 on Model 413RT)
13
1921958
2
BOLT, Hex Hd, 1/4”-20 x 1/2” (Qty. 1 on Model 413RT)
14
1716727
2
CLAMP, Cable (Qty. 1 on Model 413RT)
15
1716728
2
YOKE, Cable (Qty. 1 on Model 413RT)
16
1716703
3
COTTER PIN (Qty. 1 on Model 413RT)
17
1716702
2
PIN, Link (Qty. 1 on Model 413RT)
18
1716707
1
LEVER, Handlebar Tilt
19
1716714
1
STOP, Handlebar Tilt Lever
20
1716715
1
BOLT, 8mm x 16mm
21
1716708
1
KNOB, Handlebar Tilt Lever
22
1716716
2
BOLT, 10mm x 30mm
23
1923141 *
2
BOLT, Hex Hd, 5/16” - 18 x 2-3/4”, Grade 5
24
1716724
1
COVER, Transmission Wheel Housing
25
1716710
1
SPRING, Handlebar Swivel
26
1716719
1
MOUNT, Handlebar Stem, Left
27
1716706
1
MOUNT, Handlebar Stem, Right
28
1935048 *
2
NUT, Bi-way Lock, 5/16”-18
29
1716717
2
NUT, Nyloc, 10mm
30
1716712
1
LEVER, Handlebar Swivel
31
1716711
1
KNOB, Handlebar Swivel Lever
32
1716713
1
HANDLEBAR STEM
33
1716705
2
TILT FRICTION PAD
34
1931339
4
BOLT, Carriage Hd, 5/16”-18 x 2”
35
1716731
4
BOLT, Hex Hd, 5mm x 0.8mm x 10mm
36
1716730
1
NUT, Nyloc, #10 — Model 516RT Only
37
1921978
1
BOLT, Hex Hd, 5/16”-18 x 2”, Grade 5 — Model 516RT Only
38
1716704
1
BUSHING, Pivot, 5/16” — Model 516RT Only
39
1716725
1
REVERSE HANDLE — Model 516RT Only
40
1716729
1
REVERSE LINK — Model 516RT Only
41
1716701 *
4
BOLT, Hex Flange Hd, 5/16”-18 x 1/2”, Grade 5
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
* Serial Nos. 50624 and above use Ref. Nos. 23 & 28. Units prior to Serial No. 50624 use Ref. No. 41.
The above parts group applies to the following Mfg. Nos.:
1692876 413RT, 3.5HP Rear Tine Tiller
1692877 516RT, 5HP Rear Tine Tiller
