Simplicity 516RT - Manual (Page 19)

17 TP-400-2033-00-RT-S
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* No servicable parts - components shown for ref. only.
The above parts group applies to the following Mfg. Nos.:
1692878 Hiller/Furrower Attachment (Ref. Info Only)
1 1692878 1 HILLER/FURROWER, Complete (Order as Wholegood)
2 * 1 BOLT, Soc Hd, 3/8”-16 x 1-1/4”
3 * 1 BRACKET
4 * 1 NUT, Hex, 3/8” - 16
5 * 2 NUT, Nyloc, 3/8” - 16
6 * 1 BLADE, Furrower
7 * 2 BOLT, Carriage, 3/8 - 16 x 1-1/2”
8 * 4 BOLT, Carriage, 5/16” - 18 x 3/4”
9 * 1 HILLER WING, Left
9 * 1 HILLER WING, Right (Not Shown)
10 * 4 WASHER, Flat, 5/16”
11 * 4 LOCKWASHER, External Tooth, 5/16”
12 * 4 WING NUT, 5/16 “- 18
1692876 413RT, 3.5HP Rear Tine Tiller
1692877 516RT, 5HP Rear Tine Tiller
1692878 Hiller/Furrower Attachment
