Download Graphics Printing
When the 7
×
9 (half dot) character size (default setting) is set:
n2 – n1 + 1
1B 26 00 n1 n2 [m0 m1 m2 m3 m4 m5 m6 m7]
n2 – n1 + 1
When the 5
×
9 dot character size is set:
n2 – n1 + 1
1B 26 00 n1 n2 [m0 m1 m2 m3 m4 m5]
n2 – n1 + 1
Defines download character (7
×
9 (half dot) font or 5
×
9 dot font)
Defines download characters
Up to 10 download characters can be defined and the defined
character patterns can be stored in the printer’s RAM.
The values of n1 and n2 are between (21)
H
and (7F)
H
with n1 less
than or equal to n2 and the value of m0 is either (00)
H
or (80)
H
.
Defining of download characters begins with character code n1 and
completes with n2. When only one character is defined, n1 = n2.
m0 indicates the relationship between the character pattern and print
head.
m1 m2.... Indicate the character pattern
CODE
HEX
CODE
HEX
FUNCTION
MSB
When m0=(00)H
LSB
D
8
D
7
D
6
D
5
D
4
D
3
D
2
D
1
1
2
3
4
5
6
7
8
9
Pin No.
(Not used)
MSB
When m0=(80)H
LSB
D
8
D
7
D
6
D
5
D
4
D
3
D
2
D
1
1
2
3
4
5
6
7
8
9
Pin No.
(Not used)
