Respect the clearances and maximum lengths indicated in the diagram below when installing the unit.
125mm
(5inch)
or more
600mm
(24inch)
minimum
350mm(14inch)
minimum
100mm
(4inch)
minimum
600mm
(24inch)
minimum
100mm(4inch)
minimum
20m(65ft. 7in)
maximum
8m(26ft. 3in)
maximum
P
REPARING THE
I
NSTALLATION
30mm(1inch) or more
125mm(5inch)
or more
Wrap the refrigerant pipes and the drain
hose up in the absorbent pad and the
vinyl tape; refer to page 45.
