DE2-70 User Manual
64
SRAM_DPA2 PIN_AK20 SRAM Parity Data[2]
SRAM_DPA3 PIN_AJ9 SRAM Parity Data[3]
SRAM_GW_N PIN_AG18 SRAM Global Write Enable
SRAM_OE_N PIN_AD18 SRAM Output Enable
SRAM_WE_N PIN_AF18 SRAM Write Enable
Table 5.20. SSRAM pin assignments.
Signal Name FPGA Pin No. Description
FLASH_A[0] PIN_AF24 FLASH Address[0]
FLASH_A[1] PIN_AG24 FLASH Address[1]
FLASH_A[2] PIN_AE23 FLASH Address[2]
FLASH_A[3] PIN_AG23 FLASH Address[3]
FLASH_A[4] PIN_AF23 FLASH Address[4]
FLASH_A[5] PIN_AG22 FLASH Address[5]
FLASH_A[6] PIN_AH22 FLASH Address[6]
FLASH_A[7] PIN_AF22 FLASH Address[7]
FLASH_A[8] PIN_AH27 FLASH Address[8]
FLASH_A[9] PIN_AJ27 FLASH Address[9]
FLASH_A[10] PIN_AH26 FLASH Address[10]
FLASH_A[11] PIN_AJ26 FLASH Address[11]
FLASH_A[12] PIN_AK26 FLASH Address[12]
FLASH_A[13] PIN_AJ25 FLASH Address[13]
FLASH_A[14] PIN_AK25 FLASH Address[14]
FLASH_A[15] PIN_AH24 FLASH Address[15]
FLASH_A[16] PIN_AG25 FLASH Address[16]
FLASH_A[17] PIN_AF21 FLASH Address[17]
FLASH_A[18] PIN_AD21 FLASH Address[18]
FLASH_A[19] PIN_AK28 FLASH Address[19]
FLASH_A[20] PIN_AJ28 FLASH Address[20]
FLASH_A[21] PIN_AE20 FLASH Address[21]
FLASH_DQ[0] PIN_AF29 FLASH Data[0]
FLASH_DQ[1] PIN_AE28 FLASH Data[1]
FLASH_DQ[2] PIN_AE30 FLASH Data[2]
FLASH_DQ[3] PIN_AD30 FLASH Data[3]
FLASH_DQ[4] PIN_AC29 FLASH Data[4]
